388
TCNT—Timer Counter H'FFC6 PWM2
Bit 76543210
Initial value 00000000
Read/Write R/(W)* R/(W)* R/(W)* R/(W)* R/(W)* R/(W)* R/(W)* R/(W)*
Note: Bit functions are the same as for PWM1.
* Write function is for test purposes only. Writing to this register during normal operation may have
unpredictable effects
TCR—Timer Control Register H'FFC8 PWM3
Bit 76543210
OE OS — — — CKS2 CKS1 CKS0
Initial value 00111000
Read/Write R/W R/W — — — R/W R/W R/W
Note: Bit functions are the same as for PWM1.
DTR—Duty Register H'FFC9 PWM3
Bit 76543210
Initial value 11111111
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Note: Bit functions are the same as for PWM1.
