387
TCNT—Timer Counter H'FFC2 PWM1
Bit 76543210
Initial value 00000000
Read/Write R/(W)* R/(W)* R/(W)* R/(W)* R/(W)* R/(W)* R/(W)* R/(W)*
* Write function is for test purposes only. Writing to this register during normal operation may have
unpredictable effects
Count value (runs from H'00 to H'F9, then repeats from H'00)
TCR—Timer Control Register H'FFC4 PWM2
Bit 76543210
OE OS — — — CKS2 CKS1 CKS0
Initial value 00111000
Read/Write R/W R/W — — — R/W R/W R/W
Note: Bit functions are the same as for PWM1.
DTR—Duty Register H'FFC5 PWM2
Bit 76543210
Initial value 11111111
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Note: Bit functions are the same as for PWM1.
