390
TCR—Timer Control Register H'FFD0 TMR
Bit 76543210
CMIEB CMIEA OVIE CCLR1 CCLR0 CKS2 CKS1 CKS0
Initial value 00000000
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Counter Clear
0 0 Counter is not cleared.
0 1 Cleared by compare-match A.
1 0 Cleared by compare-match B.
1 1 Cleared on rising edge of external reset input.
Clock Select
0 0 0 No clock source; timer stops.
0 0 1 Internal clock source: ø8,
counted on falling edge.
0 1 0 Internal clock source: ø64,
counted on falling edge.
0 1 1 Internal clock source: ø1024,
counted on falling edge.
1 0 0 No clock source; timer stops.
1 0 1 External clock source, counted
on rising edge.
1 1 0 External clock source, counted
on falling edge.
1 1 1 External clock source, counted
on both rising and falling edges.
Timer Overflow Interrupt Enable
0 Overflow interrupt request is disabled.
1 Overflow interrupt request is enabled.
Compare-Match Interrupt Enable A
0 Compare-match A interrupt request is disabled.
1 Compare-match A interrupt request is enabled.
Compare-Match Interrupt Enable B
0 Compare-match B interrupt request is disabled.
1 Compare-match B interrupt request is enabled.
