TCORA—Time Constant Register A H'FFD2 TMR
Bit 76543210
Initial value 11111111
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
The CMFA bit is set to 1 when TCORA = TCNT.
TCORB—Time Constant Register B H'FFD3 TMR
Bit 76543210
Initial value 11111111
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
The CMFB bit is set to 1 when TCORB = TCNT.
TCNT—Timer Counter H'FFD4 TMR
Bit 76543210
Initial value 00000000
Read/Write R/W R/W R/W R/W R/W R/W R/W R/W
Count value
