Honeywell VideoBloX User Manual

Honeywell
85
Field Definitions
Field Description
HEADING
Keyboard Number Number assigned to the keyboard being configured.
Keyboard Name Name associated with this keyboard.
This name is retrieved from the NAME section on this tab.
NAME
Name associated with this keyboard. The Keyboard Name
can be up to 24 characters. The keyboard name is used for
reference and reporting. The keyboard name is not
outputted on the PVT channel.
Short Name Abbreviated name associated with this keyboard
(up to 12 characters).
KEYBOARD DETAIL
Keyboard Address Actual keyboard connection number.
Type Type of keyboard attached to this address.
Options are Com and Ethernet.
IP Address N/A (For use in future development).
DEDICATED MONITOR
Enabled When enabled, allows for automatic switching to a dedicated
monitor output.
Physical O/P Physical address of the dedicated monitor, if enabled.
LOGIN SEQUENCE
Enabled When enabled, triggers a sequence to run when someone
logs in at this keyboard.
Sequence Drop down box used to select (by name) the sequence to run
when someone logs in at this keyboard. Sequence name
selected correlates with sequence number.
Sequence Number Drop down box used to select (by number) the sequence to
run when someone logs in at this keyboard. Sequence
number selected correlates with sequence name.
Edit Used to edit the sequence selected for login.
LOGOUT SEQUENCE
Enabled When enabled, triggers a sequence to run when someone
logs out at this keyboard.
Sequence Drop down box used to select (by name) the sequence to run
when someone logs out at this keyboard. Sequence name
selected correlates with sequence number.
Sequence Number Drop down box used to select (by number) the sequence to
run when someone logs out at this keyboard. Sequence
number selected correlates with sequence name.
