63
Outputs can be in more than one group at a time.
Select
to save/download all information from the current page.
Output Group Names
The Outputs Group Names tab is used to set up meaningful groupings/names for
outputs.
Figure 3-15 Outputs – Group Names Configuration
Field Definitions
Field Description
HEADING
Output Number Number assigned to the video output being configured.
Carries over from Outputs Detail window.
GROUP NUMBER
Number assigned to each outputs group.
GROUP NAME
Text entered to name/identify a particular outputs group.
Steps for Configuring Output Group Names
1. Select a group number to use.
NOTE: Group number is an editable text field capable of accepting numeric values. In the
database, the group number is still defined as originally set.
Group
names tab
