Honeywell VideoBloX User Manual

VideoBloX MODULES
12
SW 6 Video source detection
0= Don’t detect video source
1= Detect video source on input car
SW 7 Loss video skip
0= Include channel on video loss
1= Skip Channel on video loss
SW 8
Web password
initialization
1 = Reset to default NETCPU web password
( The default password is “1234”)
0 = No action
DIP switch 3 is reserved for future usage except the last three bits.
Position Use Description
SW 1 NETCPU Reserved
SW 2 NETCPU Reserved
SW 3 NETCPU Reserved
SW 4 NETCPU Reserved
SW 5 NETOSD Reserved
SW 6
SW7
SW8
Language Selection
SW8-SW6
000 means China and English
100 means Korean and English
DIP switch 4 is used to set various parameters relating to NETOSD.
Position Use Description
SW 1 –SW 5 Output Group Address
Refer to Output Group Address section for
detailed information
SW 6 PAL/NTSC
0 = PAL
1 = NTSC
SW 7
Restore option( Act
depend on switch 2
SW1)
0 = Restore OSD setting except font
library during system restore
1 = Restore OSD setting and font library
during system restore
SW 8 Reset Web Password Changing from 0 to 1 resets web password
Output Group Address
Unit address can be set via switch 4. Following table display the relationship between
switch 4 and address value.
SW4.5 SW4.4 SW4.3 SW4.2 SW4.1 Unit Address
Off Off Off Off Off 0
