6 APPENDIX B: Backward Compatible Application
Introduction
The new modules Honeywell offers to our users provide good backward compatible
ability.
The old users can interface their old VideoBloX system with new modules seamlessly. In
this way, users are able to expend their system capacity with new modules.
Interface new input module with old system
Honeywell’s VideoBloX input module provides on board jumpers to let the user select the
input module to be either backward compatible or forward compatible.
Figure 6-1 HVBM64 Jumper position
If there are LKO or HVB16TO in chassis, J1 should be installed.
If there is HVB16TO board in chassis, J2~J17 should be installed.
Note: HVB16TO is the old title display board.
