SYSTEM CONFIGURATION
82
Figure 3-24 Users – Access Configuration
ADDITIONAL INFORMATION:
• Sample Device types are VCRs, DVRs, etc.
• Functions are features that users can perform using the keyboard (assuming it is
capable and has permission). Access for functions using this tab allows/prohibits the
capabilities of the user. The access set on this tab determines what the user is
allowed to do. For example, if the keyboard is capable of performing a function but the
user logged in is prohibited, the function is not allowed. If the keyboard is prohibited
from performing a function even though the user is allowed, the function is not allowed.
The following functions are set up by default: Switch matrix, PTZ control, PTZ preset
store, PTZ preset store 1..32 store, PTZ preset 33..64 store, PTZ preset 65..128 store,
Device Control (inhibits use of device button), Sequence Run, Alarm Accept, Login,
Logout. Others are useless.
Field Definitions
Field Description
HEADING
User Number Number assigned to the user being configured.
This field carries over from the Detail screen.
User Name User name as defined in the Detail screen.
GROUP NAME
(COLUMN)
Available groups are displayed in columns.
(Groups shown depend on sub-level selected.)
USER ACCESS
(ROW)
Indicates the groups in which the user is included / excluded.
(Groups shown depend on sub-level selected.)
Access
Button
Heading
Access tab
To Next Page
