Honeywell VideoBloX User Manual

Honeywell
111
Figure 3-50 Sequences – Access Configuration
Field Definitions
Field Description
HEADING
Sequence Number Number assigned to the keyboard being configured.
This field carries over from the Detail screen.
Sequence Name Name associated with this keyboard.
This field carries over from the Detail screen.
GROUP NAME
(COLUMN)
Available groups are displayed in columns.
SEQUENCE
ACCESS (ROW)
Indicates the groups in which the sequence is included /
excluded.
Steps for Configuring Sequence Access
1. From the Sequence screen, select the Access Tab.
2. Set access for each sequence using the following methods:
• Click on the Access button to include this sequence in / exclude this sequence
from ALL groups. (Include = 9 / Exclude = U). Click on the Access button again
to toggle between include/exclude settings.
• Click on a Group column or on an individual cell (in the Access row) on the table
to include
this sequence in / exclude this sequence from the particular group.
Access Button
Heading
Access tab
