Page #77 background imageLoading...
Page #77 background image
Honeywell
61
OUTPUT NOTES
Free-form field.
i.e., “17-in Monitor – Top Left in Surveillance Bay 2”
LOCATION
Enable Enable output title.
X pos X position of the output title
Y pos Y position of the output title
Steps for Configuring Video Output Detail
1. On the Outputs screen, select the Detail tab on the right side of the window.
2. Select the Output Number to be used for this output.
3. Enter the Physical O/P address of the output connection.
4. Select Monitor for the Output. Other options are intended for future releases of the
Matrix Switcher.
5. Enter/edit the Output Name. Include the output number in the name entered as it
does not appear on its own in displays or reports.
6. Enter/edit a Short Name for the output.
7. If audio is associated with this output, check the box to Enable audio and
enter the physical address of the audio output.
8. Enter Notes about this output in this free-form field. It is helpful to include the output
location in this field.
9. Select
to save/download all information from the current page.
Output Access
The Outputs Access tab is used to set permissions for all video outputs.
