6. Select the defined Brightness option for the Title and time display.
7. Enter an X Position and Y Position for the Display Origin. Display Origin is the
starting point for the text block. These values move the entire block of text to a new
location on the monitor. The values X=8, Y=8 place the text block in the upper left
corner of the screen.
8. Enter an X Position and Y Position for the Date/Time display. These values set the
location of the Date/Time display. Default values X=1, Y=1 place the Date/Time
display at the bottom left of the screen.
9. Check the Output box if information will be provided by a Title Output Card in the
Video Matrix.
10. If the Output box is not checked, enter the I/P channel of the Input Titler associated
with this input.
11. Select
to save/download all information from the current page.
Input Access
The Inputs Access capability allows inputs to be assigned to a Group.
The Groups are then used in defining the privileges an operator has for viewing, editing,
and controlling specific Groups.
Figure 3-10 Inputs – Access Configuration
Access Button
