An example of satellite addresses setting.
Here are 2 sub-VBs and one Main VB. The Main VB is an original VB. The two sub-VBs
are connected to each other via Ethernet. One of the two sub-VBs (called VB1) is
connected to the Main VB.
The Link setting of Main VB is described in the following table. Its IP is 192.168.1.11.
Address Type IP Comment
1 Ethernet 192.168.1.11 Same with Main VB’s IP. the Main
VB’s satellite address is 1.
2 Ethernet 192.168.1.12 Address 2 is a Net VideoBloX.
3 Local NULL Address 3 is an original VB. Connect
Main VB via Com2.
The Link setting of sub-VB whose IP is 192.168.1.12 is described in the following table.
Address Type IP Comment
1 Ethernet 192.168.1.11 Address 1 is a Net VideoBloX.
2 Ethernet 192.168.1.12 Same with Sub VB’s IP, so the
Sub VB’s satellite address is 2.
3 Ethernet 192.168.1.11 Although this VB is an original VB,
but it connect to Main VB, so
when Sub VB wants to control this
VB, the Sub VB still needs to
send commands to Main VB, and
then Main VB will transfer the
commands to the original VB.
OUTPUTS (Adding a video output)
Outputs Detail
The fields necessary to add a video output are on the Outputs tab.
The Outputs Detail tab is used to enter all physical characteristics for a video output.
