SYSTEM CONFIGURATION
100
• Valuable tool for selecting cameras
• Switches a view to the currently selected monitor
- User-Defined Keys (UDK) are defined as Groups.
- Press the button corresponding to the required Group.
- Select the number within that group to view, and then press Enter.
- Select next / previous Scene within the group using the Next / Prev keys.
- Select alternate views for a scene by pressing the Enter key.
Device Control Mode
Figure 3-42 Device Control Mode
• The keyboard is not just a means of controlling camera switching but is a
programmable control keyboard, used for controlling many other devices
such as VCRs, DVRs, Multiplexers, and printers.
• Select a Device
- Press the VCR button and enter the devices type’s number – press Enter.
- Once the Device type is selected, enter the device number – press Enter.
Sanyo VCR Control
Figure 3-43 Sanyo VCR Control
• VCR – Number
- VCR Output will be displayed on selected monitor.
