SYSTEM CONFIGURATION
90
Figure 3-28 Keyboards – Access Configuration
ADDITIONAL INFORMATION:
• The Keyboards Æ Access Æ Keyboards sub-level is not needed for setup.
• Sample Device types are VCRs, DVRs, etc.
• Functions are features that users can perform using the keyboard.
Access for functions using this tab allows/prohibits the capabilities of the keyboard
itself. The access set on this tab determines what the keyboard is capable of
performing, not what the user is allowed to do. For example, if the keyboard is capable
of performing a function but the user who logged in is prohibited, the function is not
allowed. If the keyboard is prohibited from performing a function even though the user
is allowed, the function is not allowed. The following functions are set up by default:
Switch matrix, PTZ control, PTZ preset store, PTZ preset store 1..32 store, PTZ preset
33..64 store, PTZ preset 65..128 store, Device Control (inhibits use of device button),
Sequence Run, Alarm Accept, Login, Logout. Others are useless.
Field Definitions
Field Description
HEADING
Keyboard Number Number assigned to the keyboard being configured.
This field carries over from the Detail screen.
Keyboard Name Name associated with this keyboard.
This field carries over from the Detail screen.
GROUP NAME
(COLUMN)
Available groups are displayed in columns.
(Groups shown depend on sub-level selected.)
Access
Button
Heading
Access tab
