Honeywell VideoBloX User Manual

SYSTEM CONFIGURATION
58
Links (Setting satellite)
Figure 3-12 Inputs – Group Names Configuration
Field Definitions
Field Description
HEADING
Address Number assigned to the Satellite being configured.
IP address Set the satellite VedioBloX IP which connects to this VB, if
the IP is equal to the Machine you are setting, the address
you are setting will be set as this VB’s satellite address.
IP Port Set IP port. The default value is 8888.
Name The name of satellite VB
Type ‘Ethernet’ is the NET VB; ‘Local’ is the original VB.
DETAIL
Trunk Set the Trunk. The system will switch input of other VB to
the remote output, and switch the local input to the output
users chosen. The Remote output and Local input are
connected witch BNC line.
Local priority The operation priority of the satellite VB on the VB user is
setting. (For future use.)
