Honeywell VideoBloX User Manual

SYSTEM CONFIGURATION
56
Field Definitions
Field Description
HEADING
Input Number Number assigned to the video input being configured.
Carries over from Inputs Detail window.
Camera Name Camera title associated with this video input as edited in the
Inputs Title tab.
Camera Short Name Abbreviated camera title associated with this video input as
edited in the Inputs Title tab.
GROUP NAME
(COLUMN)
Available groups (up to 128, as defined on the Inputs Group
Name tab) are displayed in columns.
INPUT ACCESS
(ROW)
Indicates the groups in which the input is included /
excluded.
Steps for Configuring Input Access
Set access for each video input using the following methods:
• Click on the Access button to include this input / exclude this input from ALL
groups.
(Include = 9 / Exclude = U). Click on the Access button again to toggle between
include/exclude settings.
• Click on a Group column or on an individual cell (in the Access row) of the table to
include this input / exclude this input from a particular group. (Include = 9 /
Exclude = U). Click on the Group again to toggle between include/exclude
settings.
Cameras can be in more than one group at a time.
Select
to save/download all information from the current page.
Input Group Names
The Inputs Group Names tab is used to set up meaningful groupings/names for inputs.
