SYSTEM CONFIGURATION
118
Figure 3-54 Device – General Configuration
Field Definitions
Field Description
Device Type Defines the type of device you are controlling. There are a
maximum of 32 device types.
Definition File Enter the database file name that defines the device type.
Click on
to browse the system to locate the desired file.
Note: The database file is created previously by using the
software program, NETCPU Device Config.
Name Enter a meaningful name to define the device (e.g. VCR,
DVR, etc.)
Switch Offset A number that is added to the selected device for automatic
matrix switching. The field entries include:
–1 for no switching when the device is selected
0 (switches to # selected)
thru
xx (switches to #+xx selected).
Maximum Maximum number of devices that can be controlled for that
device type.
Steps for Configuring a Device
1. From the Devices screen, select General.
2. Select the Device Type to configure. There are a maximum of 32 device types.
To Next Page
