SYSTEM CONFIGURATION
54
display origin.
Y Pos The Title’s vertical offset relative to the Y position of the
display origin.
Style Specifies the Title’s on-screen appearance
(Text / Keyline / Background).
DISPLAY ORIGIN
X Pos The horizontal position from the left side of the screen for all
text display. Default value is 8 (top of the screen).
Y Pos The vertical position from the left side of the screen for all
text display. Default value is 8 (left of the screen).
DATE / TIME
X Pos The Date / Time’s horizontal offset relative to the X position
of the display origin.
Y Pos The Date / Time’s vertical offset relative to the Y position of
the display origin.
Style Specifies the Title’s on-screen appearance
(Text / Keyline / Background).
TITLE LOCATION
Output If the Output box is checked, the title is generated from the
Video Output Module installed in the chassis.
If the Output box is not checked, the title comes from the
PVT Channel. (In this situation, it is important to know the
PVT channel associated with the Video Input on the Matrix.)
I/P Channel Channel number for an input titler associated with this input.
(For future function.)
Brightness The brightness of the title.
Steps for Configuring Input Title
1. On the Inputs screen, select the Title tab on the right side of the window.
The heading information for the input (number, name, abbreviated name)
remains visible.
2. Enter/edit the input Name. Include the input number in the camera name entered as
it does not appear on its own in displays or reports.
3. Enter/edit a Short Name for the input. For example, “Cam 8899 PTZ West Lobby”
4. Enter an X Position and Y Position for the Title Display. These fields provide for
offsets of the text within the display field available. Note, however, that selecting an
offset changes the number of characters that will be visible on a monitor.
Maximum X value = 40; Maximum Y value = 28.
5. Select the Style of the displayed text and time.
