Honeywell VideoBloX User Manual

SYSTEM CONFIGURATION
108
Parm1 Used to enter an applicable parameters value for this
command (as needed). More detailed information for this
parameter is displayed in the Parameter 1 field below the
sequence table.
Parm2 Used to enter an applicable parameters value for this
command (as needed). More detailed information for this
parameter is displayed in the Parameter 2 field below the
sequence table.
Parm3 Used to enter an applicable parameters value for this
command (as needed). More detailed information for this
parameter is displayed in the Parameter 3 field below the
sequence table.
Parm4 Used to enter an applicable parameters value for this
command (as needed). More detailed information for this
parameter is displayed in the Parameter 4 field below the
sequence table.
Comment Free text field for comments.
DEFINITIONS
Command Description Descriptive field for command.
Parameter 1 Description Descriptive field for Parameter 1.
Parameter 2 Description Descriptive field for Parameter 2.
Parameter 3 Description Descriptive field for Parameter 3.
Parameter 4 Description Descriptive field for Parameter 4.
COMMANDS
Delete Sequence Delete this entire sequence.
Create Sequence Create a new sequence.
Quit Stop all changes.
Save to Flash Saves all sequences which have been downloaded to the
NetCPU to the NetCPU flash memory.
Steps for Defining Sequences
1. On the Sequences screen, select the Editor tab on the right side of the window.
2. Select the Sequence Number to be defined. If the sequence is “blank” (not
previously defined), the Create Sequence key will be available. Select Create
Sequence. The END command will be the only command included in the sequence.
3. Click
to add a record to the sequence.
4. Click in the Command cell of the newly created row. The drop-down box will show
which commands are available. Select the appropriate command.
5. Review the parameters related to this command and enter appropriate values in the
Parm1, Parm2, Parm3, or Parm4 field(s) necessary. Enter any comments that may
be helpful.
