VideoBloX MODULES
38
Set the “End Address” SW3 (1-8) and SW4 (1-3) to match the address of the last
input card within the connected sub-chassis.
SW4 (4-5) are reserved for future use to select protocols.
SW4 (6) is used for testing to switch inputs to the outputs, camera 1 to monitor 1,
camera 2 to monitor 2, camera 15 to monitor 15, etc.
Turn SW4 (7) to on to enter test mode. In test mode, the module cycles various
inputs to outputs. This is useful for bench-top fault-finding and should not
normally be used in the field.
SW4 (8) is not used.
