119
3. Click Add.
The Add SNMP Group page appears.
Figure 109 Creating an SNMP group
4. Configure SNMP group as described in Table 36.
5. Click Apply.
Table 36 Configuration items
Item Descri
Group Name Set the SNMP group name.
Security Level
Select the security level for the SNMP group:
• NoAuth/NoPriv—No authentication no privacy.
• Auth/NoPriv—Authentication without privacy.
• Auth/Priv—Authentication and privacy.
IMPORTANT:
For an existing SNMP group, its security level cannot be modified.
Read View Select the read view of the SNMP group.
Write View
Select the write view of the SNMP group.
If no write view is configured, the NMS cannot perform the write operations to all
MIB objects on the device.
Notify View
Select the notify view (the view that can send trap messages) of the SNMP group.
If no notify view is configured, the agent does not send traps to the NMS.
ACL
Associate a basic ACL with the group to restrict the source IP address of SNMP
packets. To restrict the intercommunication between the NMS and the agent, you
can allow or prohibit SNMP packets with a specific source IP address.
