HP 1920 Gigabit Ethernet Switch Series User Manual

486
Table 159 Configuration items
Item Descri
p
tion
WRR
Setup
WRR
Enable or disable the WRR queue scheduling mechanism on selected ports. The
following options are available:
• Enable—Enables WRR on selected ports.
• Not Set—Restores the default queuing algorithm on selected ports.
Queue
Select the queue to be configured.
The value range for a queue ID is 0 to 7.
Group
Specify the group the current queue is to be assigned to.
This list is available after you select a queue ID. The following groups are available
for selection:
• SP—Assigns a queue to the SP group.
• 1—Assigns a queue to WRR group 1.
Weight
Set a weight for the current queue.
This list is available when group 1 is selected.
Please select port(s) Click to select ports to be configured with queuing on the chassis front panel.
Configuring rate limit on a port
1. Select QoS > Line rate from the navigation tree.
2. Click the Setup tab to enter the rate limit configuration page.
Figure 472 Configuring rate limit on a port
3. Configure rate limit on a port as described in Table 160.
4. Click Apply.
Table 160 Configuration items
Item Descri
p
tion
Please select an interface type Select the types of interfaces to be configured with rate limit.
