485
Figure 470 Applying a policy to a port
3. Apply a policy to a port as described in Table 158.
4. Click Apply.
Table 158 Configuration items
Item Descri
tion
Please select a policy
Select an existing policy in the list.
Direction
Set the direction in which the policy is to be applied.
• Inbound—Applies the policy to the incoming packets of the specified ports.
• Outbound—Applies the policy to the outgoing packets of the specified ports.
Please select port(s)
Select one port to which the QoS policy is to be applied on the chassis front panel.
Configuring queue scheduling on a port
1. Select QoS > Queue from the navigation tree.
2. Click Setup to enter the queue scheduling configuration page.
Figure 471 Configuring queue scheduling
3. Configure queue scheduling on a port as described in Table 159.
4. Click Apply.
