481
Configuring traffic mirroring and traffic redirecting
for a traffic behavior
1. Select QoS > Behavior from the navigation tree.
2. Click Port Setup to enter the port setup page for a traffic behavior.
Figure 466 Port setup page for a traffic behavior
3. Configure traffic mirroring and traffic redirecting as described in Table 154.
4. Click Apply.
Table 154 Configuration items
Item Descri
tion
Please select a behavior
Select an existing behavior in the list.
Mirror To
Set the action of mirroring traffic to the specified destination port.
Redirect
Set the action of redirecting traffic to the specified destination port.
Please select a port
Specify the port to be configured as the destination port of traffic mirroring or
traffic directing on the chassis front panel.
Configuring other actions for a traffic behavior
1. Select QoS > Behavior from the navigation tree.
2. Click Setup to enter the page for setting a traffic behavior.
