HP 1920 Gigabit Ethernet Switch Series User Manual

260
Figure 233 Displaying detailed information about the entry
Table 85 Field description
Field Descri
p
tion
VLAN ID ID of the VLAN to which the entry belongs.
Source Address
Multicast source address. If no multicast sources are specified, this field displays
0.0.0.0.
Group Address Multicast group address.
Router Port(s) All router ports.
Member Port(s) All member ports.
IGMP snooping configuration example
Network requirements
As shown in Figure 234, IGMPv2 runs on Router A and IGMPv2 snooping runs on Switch A. Router A
acts as the IGMP querier.
Perform the configuration so Host A can receive the multicast data addressed to the multicast group
224.1.1.1.
