HP 1920 Gigabit Ethernet Switch Series User Manual

224
Setting LLDP parameters on ports
The Web interface allows you to set LLDP parameters for a single port or for multiple ports in batch.
Setting LLDP parameters for a single port
1. From the navigation tree, select Network > LLDP.
By default, the Port Setup tab is displayed.
2. Click the icon for the port.
On the page as shown in Figure 199, the LLDP settings of the port are displayed.
Figure 199 M
odifying LLDP settings on a port
3. Configure the LLDP parameters for the port as described in Table 75.
4. Click Apply.
A progress dialog box appears.
5. Click Close on the progress dialog box when the progress dialog box prompts that the
configuration succeeds.
Table 75 Configuration items
Item Descri
p
tion
Interface Name Displays the name of the port or ports you are configuring.
DLDP State
Displays the LLDP enabling status on the port you are configuring.
This field is not available when you batch-configure ports.
Basic
Settings
LLDP Operating Mode
Set the LLDP operating mode on the port or ports you are
configuring:
• TxRx—Sends and receives LLDP frames.
• Tx—Sends but does not receive LLDP frames.
• Rx—Receives but not does not send LLDP frames.
• Disable—Neither sends nor receives LLDP frames.
