280
Creating an IPv4 static route
1. Select Network > IPv4 Routing from the navigation tree.
2. Click the Create tab.
The page for configuring an IPv4 static route appears.
Figure 255 Creating an IPv4 static route
3. Create an IPv4 static route as described in Table 91.
4. Click Apply.
Table 91 Configuration items
Item Descri
Destination IP Address
Enter the destination host or network IP address in dotted decimal notation.
Mask
Enter the mask of the destination IP address.
You can enter a mask length or a mask in dotted decimal notation.
Preference
Set a preference value for the static route. The smaller the number, the higher the
preference.
For example, specifying the same preference for multiple static routes to the same
destination enables load sharing on the routes. Specifying different preferences
enables route backup.
Next Hop Enter the next hop IP address in dotted decimal notation.
