Item Descri

tion

Detection in VLAN

Sets whether the system performs loopback detection in all VLANs for the target

trunk or hybrid port.

If you select Disable, the system performs loopback detection only in the default

VLAN of the target trunk or hybrid port.

This configuration item is available only for a trunk or hybrid port.
