HP 1920 Gigabit Ethernet Switch Series User Manual

458
Item Descri
p
tion
Rule ID
Select the Rule ID box and enter a number for the rule.
If you do not specify the rule number, the system will assign one
automatically.
If the rule number you specify already exists, the following
operations modify the configuration of the rule.
Action
Select the action to be performed for packets matching the rule:
• Permit—Allows matched packets to pass.
• Deny—Drops matched packets.
Non-First Fragments Only
Select this box to apply the rule to only non-first fragments.
If you do no select this box, the rule applies to all fragments and
non-fragments.
Logging
Select this box to keep a log of matched packets.
A log entry contains the ACL rule number, operation for the
matched packets, protocol number, source/destination address,
source/destination port number, and number of matched
packets.
This function is not supported.
IP Address Filter
Source IP Address
Select the Source IP Address box and enter a source IPv4
address and a source wildcard mask, in dotted decimal
notation.
Source Wildcard
Destination IP Address
Select the Source IP Address box and enter a source IP address
and a source wildcard mask, in dotted decimal notation.
Destination Wildcard
Protocol
Select the protocol number.
If you select 1 ICMP, you can configure the ICMP message type
and code. If you select 6 TCP or 17 UDP, you can configure the
TCP or UDP port.
ICMP Type
ICMP Message Specify the ICMP message type and code.
These items are available only when you select 1 ICMP from the
Protocol list.
If you select Other from the ICMP Message list, you need to type
values in the ICMP Type and ICMP Code fields. Otherwise, the
two fields will take the default values, which cannot be changed.
ICMP Type
ICMP Code
