460
Figure 449 Configuring a rule for an Ethernet frame header ACL
3. Configure a rule for an Ethernet frame header IPv4 ACL as described in Table 141.
4. Click Add.
Table 141 Configuration items
Item Descri
tion
ACL
Select the Ethernet frame header IPv4 ACL for which you want to configure
rules.
Available ACLs are Ethernet frame header IPv4 ACLs.
Rule ID
Select the Rule ID box and enter a number for the rule.
If you do not specify the rule number, the system will assign one
automatically.
If the rule number you specify already exists, the following operations
modify the configuration of the rule.
Action
Select the action to be performed for packets matching the rule:
• Permit—Allows matched packets to pass.
• Deny—Drops matched packets.
