464
Figure 452 Configuring a rule for an advanced IPv6 ACL
3. Add a rule for an advanced IPv6 ACL as described in Table 144.
4. Click Add.
Table 144 Configuration items
Item Descri
tion
Select Access Control List (ACL)
Select the advanced IPv6 ACL for which you want to configure rules.
Rule ID
Select the Rule ID box and enter a number for the rule.
If you do not specify the rule number, the system will assign one
automatically.
If the rule number you specify already exists, the following operations
modify the configuration of the rule.
Operation
Select the operation to be performed for IPv6 packets matching the
rule:
• Permit—Allows matched packets to pass.
• Deny—Drops matched packets.
