HP MSR SERIES User Manual

234
Item Descri
p
tion
Action
Select the action to be performed for IPv4 packets matching the rule:
• Permit—Allows matched packets to pass.
• Deny—Drops matched packets.
MAC
Address
Filter
Source MAC
Address
Select the Source MAC Address box, and enter a source MAC address and
wildcard.
Source Mask
Destination MAC
Address
Select the Destination MAC Address box, and enter a destination MAC
address and wildcard.
Destination Mask
COS(802.1p priority) Specify the 802.1p priority for the rule.
Type Filter
LSAP Type
Select the LSAP Type box, and specify the DSAP and SSAP fields in the LLC
encapsulation by configuring the following items:
• LSAP Type—Frame encapsulation format.
• LSAP Mask—LSAP wildcard.
LSAP Mask
Protocol Type
Select the Protocol Type box, and specify the link layer protocol type by
configuring the following items:
• Protocol Type—Frame type. It corresponds to the type-code field of
Ethernet_II and Ethernet_SNAP frames.
• Protocol Mask—Wildcard.
Protocol Mask
Time Range Select the time range during which the rule takes effect.
