HP MSR SERIES User Manual

255
Figure 255 Creating an SNMP view (2)
Table 123 describes the configuration items for creating an SNMP view. After configuring the parameters
of a rule, click Add to add the rule into the list box at the lower part of the page. After configuring all rules,
click Apply to create an SNMP view. The view will not be created if you click Cancel.
Table 123 Configuration items
Item Descri
p
tion
View Name Set the SNMP view name.
Rule
Select to exclude or include the objects in the view range determined by
the MIB subtree OID and subtree mask.
MIB Subtree OID
Set the MIB subtree OID (such as 1.4.5.3.1) or name (such as system).
MIB subtree OID identifies the position of a node in the MIB tree, and it can
uniquely identify a MIB subtree.
Subtree Mask
Set the subtree mask.
If no subtree mask is specified, the default subtree mask (all Fs) will be used
for mask-OID matching.
Adding rules to an SNMP view
Click the icon corresponding to the specified view on the page as shown in Figure 253. The Add rule
for the view ViewDefault window appears as shown in Figure 256.
After configuring the parameters,
click Apply to add the rule for the view. Table 123 desc
ribes the configuration items for creating an
SNMP view.
