HP MSR SERIES User Manual

421
3. Configure the security policy as describe in Table 186.
4. Click Apply.
Table 186 Configuration items
Item Descri
p
tion
Name Enter a name for the security policy.
Level
Set a level for the security policy. A larger number means a higher level.
If multiple security policies are defined, the system first uses the security policy with the
highest priority to check the user host. If the host does not satisfy the security policy, the
system uses the security policy with the second highest priority, and so forth until the
host satisfies a security policy or fails security check. The resources that the user can
access are those defined in the security policy that the user first passes. Therefore, when
you configure security policies, specify more resources for a security policy that has a
higher level.
Description Enter a description for the security policy.
Policy Configuration
Set check rules for the security policy.
Check rules fall into seven categories: operating system, browser, antivirus software,
firewall, certificate, file, and process.
To pass the check of a category, a host needs to satisfy at least one rule of the category.
To pass the check of a security policy, a host must satisfy all categories of the policy.
Click the expansion button before a category to view the rule information. Click the
Add button to add a rule for the category. For more information about rule
configuration, see Table 187.
Resource
Configuration
Specify the resources that can be accessed by user hosts that satisfy the security policy.
You can select All Web Proxies, All TCP Applications, and all IP Networks. To select
specific Web proxies, TCP applications, or IP networks, click the corresponding
expansion button.
Table 187 Configuration items
Item Descri
p
tion
Operating
System
Rule Name Enter a name for the operating system rule.
Type
Specify the operating system type. A user host must run the specified type of
operating system to pass security check.
Version
Specify the operating system version. The operating system of a user host must
satisfy the version requirement to pass security check.
Patch
Specify the operating system patches. The operating system of a user host must
have the specified patches installed to pass security check.
Browser
Rule Name Enter a name for the browser rule.
Type
Specify the browser type. A user host must use the specified type of browser to
pass security check.
