652
Figure 674 Network diagram
Configuration procedure
1. Configure basic voice calls: configure a local number and the call route to Router B.
a. Configure a local number: specify the local number ID as 1111 and the number as 1111, and
bind the number to line line 1/0 on the local number configuration page.
b. Configure the call route to Router B: specify the call route ID as 2222, the destination number
as 2222, the call route type as SIP, the SIP routing as IP routing, and the destination address
as 192.168.2.2 on the call route configuration page.
2. Configure caller identity and privacy:
# Disable the sending of calling information on Route A
Select Voice Management > Local Number from the navigation tree, and then click the
corresponding icon to access the call services configuration page as shown in Figure 675.
Figure 675 Configuring call services of
the calling party
a. Select Do Not Deliver for Calling Information Delivery.
b. Click Apply.
# Configure the P-Asserted-Identity header field.
Select Voice Management > Call Connection > SIP Connection from the navigation tree, and then
click the Session Properties tab to access the session properties configuration page as shown
in Figure 676.
