HP MSR SERIES User Manual

819
Item Descri
p
tion
Select the Line(s)
Select the boxes of desired lines, and then click the Apply to Selected Line(s) button to
apply the above settings to the selected FXO lines.
E&M line configuration
Select Voice Management > Advanced Configuration > Batch Configuration from the navigation tree,
and then click the E&M Line Configuration link in the Line Management area to access the E&M line
configuration page, as shown in Figure 853.
Figure 853 E&M line configuration pag
e
Table 306 Configuration items
Item Descri
p
tion
Max Interval for
Dialing the Next
Digit
Specify the maximum interval for the user to dial the next digit.
This timer will restart each time the user dials a digit and will work in this way until all
the digits of the number are dialed. If the timer expires before the dialing is completed,
the user will be prompted to hang up and the call is terminated.
Input Gain on the
Voice Interface
When the voice signals on the line
attenuate to a relatively great extent,
increases the voice input gain value.
IMPORTANT:
Gain adjustment might lead to call failures.
You are not recommended to adjust the
gain. If necessary, do it with the guidance
of technical personnel.
Output Gain on the
Voice Interface
When a relatively small voice signal
power is needed on the output line,
increases the voice output gain value.
Select the Line(s)
Select the boxes of desired lines, and then click the Apply to Selected Line(s) button to
apply the above settings to the selected E&M lines.
ISDN line configuration
Select Voice Management > Advanced Configuration > Batch Configuration from the navigation tree,
and then click the ISDN Line Configuration link in the Line Management area to access the ISDN line
configuration page, as shown in Figure 854.
