236
Figure 199 The Global Setup tab
 Select Enable from the LLDP Enable drop-down list.
 Click Apply.
2. Configure Switch B
# Enable LLDP on port GigabitEthernet 1/0/1. (Optional. By default, LLDP is enabled on Ethernet ports.)
# Set the LLDP operating mode to Tx on GigabitEthernet 1/0/1.
 Select Network > LLDP from the navigation tree to enter the Port Setup tab, as shown in Figure 200.
Click the
icon for port GigabitEthernet 1/0/1. The page shown in Figure 201 is displayed.
Figure 200 The Port Setup tab
