7.
The client uses the received challenge to encrypt the password, and sends the encrypted password
in an EAP-Response/MD5 Challenge packet to the network access device.
8. The network access device relays the EAP-Response/MD5 Challenge packet in a RADIUS
Access-Request packet to the authentication server.
9. The authentication server compares the received encrypted password with the one it generated at
step 5. If the two are identical, the authentication server considers the client valid and sends a
RADIUS Access-Accept packet to the network access device.
10. Upon receiving the RADIUS Access-Accept packet, the network access device sends an
EAP-Success packet to the client, and sets the controlled port in the authorized state so the client
can access the network.
11. After the client comes online, the network access device periodically sends handshake requests to
check whether the client is still online. By default, if two consecutive handshake attempts fail, the
device logs off the client.
12. Upon receiving a handshake request, the client returns a response. If the client fails to return a
response after a certain number of consecutive handshake attempts (two by default), the network
access device logs off the client. This handshake mechanism enables timely release of the network
resources used by 802.1X users that have abnormally gone offline.
13. The client can also send an EAPOL-Logoff packet to ask the network access device for a logoff.
Then
14. In response to the EAPOL-Logoff packet, the network access device changes the status of the
controlled port from authorized to unauthorized and sends an EAP-Failure packet to the client.
NOTE:
In EAP relay mode, the client must use the same authentication method as the RADIUS server. On the
network access device, you only need to configure the EAP relay method.
