Figure 422 Apply the QoS policy in the inbound direction of GigabitEthernet 1/0/1
Select policy1 in the Please select a policy drop-down list.
Select Inbound in the Direction drop-down list.
Select port GigabitEthernet 1/0/1.
Click Apply. A configuration progress dialog box appears.
After the configuration is complete, click Close on the dialog box.
