Device Name Device Model Version
PN1-32I10-20E4G-AV4 2.2.2
Smart U space manager XDUD-D100-S42U V42
Cabinet electronic lock DS899 N/A
If the intelligent device does not support self-identication, perform step 5 to manually add
the device.
Step 3 Click Smart Module View in Bind Cabinets and Devices.
Step 4 In the displayed dialog box for binding IT cabinets and devices, click Auto Bind to
bind devices.
Automatic binding is supported in one-to-one and one-to-four scenarios.
● One-to-one scenario
Each cabinet corresponds to a UIM.
In this scenario, two or more types of intelligent devices are monitored in
each cabinet. The intelligent devices include the smart U space manager,
intelligent rPDU, cabinet electronic lock, and T/H sensor.
● One-to-four scenario
Four cabinets correspond to one UIM.
In this scenario, only one type of intelligent devices is monitored in each
cabinet. The port for connecting the intelligent device to the UIM must meet
the physical connection rules in Table 6-2.
– This scenario supports four types of intelligent devices: smart U space manager,
intelligent rPDU, cabinet electronic lock, and T/H sensor.
– Each port on the UIM does not support cascading.
– The UIM must be installed in the
rst cabinet, and the intelligent devices in the
following three cabinets need to be connected to the rst cabinet.
– If the actual number of IT cabinets is not an integral multiple of 4, connect cables
according to the rules. Idle COM ports on the UIM can be reserved.
– One UIM can connect to only one type of intelligent devices.
Table 6-2 Cable connection mode in the UIM one-to-four scenario
COM Port
COM1 COM3 COM5 COM7
Connected
Cabinet
Cabinet 1 Cabinet 2 Cabinet 3 Cabinet 4
COM Port COM2 COM4 COM6 COM8
ECC800 Data Center Controller
User Manual (for ECC800-Pro) 6 Feature Description
Issue 02 (2020-09-07) Copyright © Huawei Technologies Co., Ltd. 129
