Table 6-9 Setting method
Cable Connection Scenario Setting Method
The card reader with a keypad is
connected to WG_1 port on the
access actuator.
Set Logical level conguration for
reader 1 removed to High level alarm.
Logical level conguration for reader 2
removed remains as Low level alarm.
The card reader with a keypad is
connected to WG_2 port on the
access actuator.
Set Logical level conguration for
reader 2 removed to High level alarm.
Logical level conguration for reader 1
removed remains as Low level alarm.
● If the access control system uses a Card, Card and
ngerprint, or Card,
password and
ngerprint reader, retain the default value Low level alarm
for Logical level conguration for reader removed.
Step 3 Check the functions of the access control device and access actuator.
Table 6-10 Function commissioning
Check Method Normal Connection Status
Method 1: Attempt to open the door
using the congured authentication
mode.
Method 2: On the WebUI, choose
Monitoring > Aisle > Access Actuator
Group > Access Actuator n, and click
Controls to open the door remotely.
For method 1: The aisle door is opened
successfully.
For method 2: After you choose Query
> Access Event on the WebUI, you can
view the type of this access control
event.
Step 4 Check the functions of the cabinet electric lock.
Table 6-11 Function commissioning
Check Method
Normal Connection Status
Method 1: Ensure that the cabinet
door is closed, and attempt to open
the door with an IC card.
Method 2: On the WebUI, choose
Monitoring > Cabinet > IT Cabinet n
> E-LOCK n, and click Controls to
open the door remotely.
For method 1: Swipe an authorized IC
card, press the lower part of the
cabinet electronic lock when the green
indicator blinks, and open the cabinet
electronic lock.
For method 2: After the cabinet
electrical lock is remotely opened,
press the lower part of the cabinet
electronic lock after the green
indicator blinks, and open the cabinet
electronic lock. Choose Query >
Access Event on the WebUI, you can
view the type of this access control
event.
