Context
Table 8-14 PDU2000 basic Information
Vendor Name
Displayed on
the WebUI
Eleventh and Twelfth
Characters in Device
Barcode
a
Clever PDU2000-M(C) FT
Haipengxin PDU2000-M(H) 6B
a: The barcode starts with 21 and is attached to the device.
Procedure
Step 1 Set the PDU2000 monitoring parameters.
● Set the PDU2000-M (C) monitoring parameters.
NO TE
The display of a single-phase module is used as an example.
– After the PDU2000-M (C) is powered on, the LCM displays the
initialization screen.
Figure 8-13 PDU2000-M (C) initialization screen
– Press MENU to enter the device communications address screen.
Figure 8-14 PDU2000-M (C) communications settings
– Set address to 1 by pressing DOWN and UP.
