(13) Wiegand ports (14) Spare fuse box (15) Indicators (16) BLINK button
Specications
Table 3-39 Indicators
Item Specications
Power Input ● AC IN: one AC input, 90 V AC to 240 V AC
● 48 V DC input: terminal, with an input voltage of 36 V DC
to 60 V DC
Power output ● AC OUT1: two AC outputs, 90 V AC to 240 V AC. The
maximum current of each output is 5 A.
● AC OUT2: one AC output, 90 V AC to 240 V AC. The
maximum current is 5 A.
LAN port FE communication with a communications rate of 10/100
Mbit/s
Wireless
communication
One wireless port that complies with IEEE 802.15.4, mutual
backup with FE communication
RS485 serial
port
COM1/COM2: two RS485 ports (one route) with a default
communication rate of 9600 bit/s, physical port cascading
(reserved)
COM3: southbound or northbound communication (reserved)
DO/DI port ● Access: One DO output port is used to control the power
output of the electronic door lock, and one DI input port is
used to connect to the door status switch. Both ports use
terminals.
● Skylight: One DO output port is used to control the power
output of the skylight magnetic lock, and one DI input port
is connected to the skylight open button. Both ports use
terminals.
DO/12V One DO port with 12 V DC power supply (reserved)
AI/DI port Five AI/DI ports, in which one is for detecting one door open
button, two for detecting lighting buttons, and one for
detecting re extinguishing linkage signal. One port is
reserved.
Wiegand port Two Wiegand ports, 12 V DC card reader operating power
output; two routes of card readers can operate at the same
time.
BLINK button ● Press the button for less than 1 second to start blinking.
● Hold down the button for 1–5 seconds to search for a
network and start networking.
● Hold down the button for more than 6 seconds to clear
network parameters.
ECC800 Data Center Controller
User Manual (for ECC800-Pro) 3 Device Description
Issue 02 (2020-09-07) Copyright © Huawei Technologies Co., Ltd. 45
