Specications
Table 3-43 Skylight actuator technical specications
Item Specications
Power input ● DC input: terminal, with an input voltage of 36 V DC–60 V
DC
● PoE power supply: one PoE port that complies with
IEEE802.3at
PoE port FE communication with the rate of 10/100 Mbit/s
Wireless
communicatio
n
One wireless port that complies with IEEE 802.15.4, mutual
backup with FE communication
AI/DI port Two AI/DI ports for detecting re extinguishing linkage signals;
smoke detection signals also supported
DO output One 12 V DC power output for controlling the skylight
magnetic lock; driving nine skylight magnetic locks
simultaneously
DI input One DI input port for connecting to the window open button
BLINK button ● Press the button for less than 1 second to start blinking.
● Hold down the button for 1–5 seconds to search for a
network and start networking.
● Hold down the button for more than 10 seconds to clear
network parameters.
Address DIP
switch
4-pin address DIP switch
E-label Supported
Indicators
Table 3-44 Skylight actuator indicators
Indicator
Color Name Status Description
Power Green Power input
status
indicator
Steady on The power input is normal.
O There is no power input.
RUN Green Running
status
indicator
O The power is abnormal or
the board program is
loading.
