Pin De
nitio
n
BCB_IN
Signal
Descriptio
n
BCB_OUT
Signal
Description
Status
Description
Initial
Status
Descripti
on
3 DRV Controls
battery
circuit
breaker
trip and
receives 12
V driving
signals
● 0 V:
There is
no
driving
signal for
BCB
tripping.
● 12 V:
There is
a driving
signal for
BCB
tripping.
0V -
4 GND Secondary
side
ground
DIP Switch
Table 3-81 DIP switch description
No.
Denition Description
1 ADDR_1 RS485 communications
address setting
2 ADDR_2
3 ADDR_3
4 ADDR_4
Indicators
Table 3-82 Indicators
Indicat
ors
Color Meaning Status Description Measure
RF_Z Green Wireless
communi
cation
status
Steady on No network
parameters
exist. (A
network is
to be
created.)
Requires no
handling.
