4-32
SECTION 4
OPERATION
To Operate with Sweep Operation:
SWEEP
Opens Sweep Configuration Window.
Enter start frequency, stop frequency, increment for
sweep operation and pause/delay times at each
frequency. Enter Pause and Delay Times.
Range is 0 to 9.5 sec with 0.5 sec step. If Pause Time
is set to zero, Delay Time is blanked.
Press F1 to start continuous sweep, F2 to stop the
sweep, F3 for single sweep and F5 to resume a halted
sweep. Press F6 to exit.
LOCK
UNLOCK
To Operate with RF Generate, RF Receive and
Spectrum Analyzer RF Frequencies locked,
press F5 until L is displayed beside RF Field.
Press F5 again to unlock.
o If Frequency List Operation is desired instead of entering frequency in RF Field,
select Frequency List Setting as follows:
On/Off
Activates Frequency List Setting.
T-Fwd
Selects Trunking Forward Channel List.
T-Rvs
Selects Trunking Reverse Channel List.
C-Fwd
Selects Cellular Forward Channel List.
C-Rvs
Select Cellular Reverse Channel List.
FL
Select User Defined Frequency List.
RF: 10.0000 MHz L
SWEEP STOP
Start: 100.0000 MHz
Stop: 200.0000 MHz
Incr: 1.0000 MHz
Pause Time: 1.0 Sec
Delay Time: Sec
RF: 10.0000 MHz
FL: OFF
Input: ANT Atten: 30 dB
Demod: FM IF BW: 15 kHz
