4-31
SECTION 4
OPERATION
4-2 RF RECEIVE OPERATION
This section provides information on configuring the COM-120C to perform tests on the
transmitter.
Press the REC MODE Key to access the RF Receive Operation Screen. In this mode,
the COM-120C to acts as a receiver to test a transmitter.
The intention is to provide sufficient information to allow the operator to effectively use
the COM-120C to perform specific operator defined tests.
4-2-1 GENERAL RF RECEIVE OPERATION
o Enter desired frequency in RF Field.
Frequency range is 0.0000 to 1000.0000 MHz.
Activate additional functions as desired.
To operate with ∆ Function active:
=
Activates window to increment RF Field. Range is 0 to
500 MHz.
On/Off
Activate/deactivate ∆ Function. Prompt displays by RF
Field.
To Operate with Scan Function:
SCAN
Opens Scan Configuration Window.
Enter start Frequency List number, end Frequency List
number and Frequency List number change increment.
Enter Pause and Delay Times.
Range is 0 to 9.5 sec with 0.5 sec step. If Pause Time
is set to zero, Delay Time is blanked.
Press F1 to start continuous sweep, F2 to stop the
sweep, F3 for single sweep and F5 to resume a halted
sweep. Press F6 to exit.
Set Steps:
0.2000= MHz
RF: 10.0000 MHz
SCAN STOP
FL From: 0
To: 99
Incr: 1
Pause Time: 1.0 Sec
Delay Time: Sec
