SECTION 4
OPERATION
300 kHz
Selects 300 kHz IF Bandwidth Filter.
15 kHz
Selects 15 kHz IF Bandwidth Filter.
30 kHz
Selects 30 kHz IF Bandwidth Filter.
T
e
n
For following guidelines, ∆F is Frequency Deviation in Hz, Φ is Phase
Deviation in Radians, Fm is the Tone Modulation Frequency in Hz and
IF is Minimum IF Filter Bandwidth. General Guidelines for IF Filter
Selection are as follows:
For FM Modulated Signals:
IF = 4(∆F + F
m
)
For PM Modulated Signals:
IF = 4F
m
(Φ + 1)
For AM Modulated Signals:
IF =15 kHz, for F
m
≤ 1 kHz
o Edit AF Generator sources as required:
GEN1
Selects GEN1 as source.
GEN2
Selects GEN2 as source.
DATA
Selects DATA as source.
DTMF
Selects DTMF as source.
RETURN
Exits source window.
RF: 10.0000 MHz
FL: OFF
Input: ANT Atten: 30 dB
Demod: FM IF BW: 15 kHz
Source: GEN1 State: ON
Format: TONE
Freq: 100.0 Hz
Shape: SINE
Level: 0.00 VP
.000 Vrms
Mode: CONT
To Next Page
