4-35
SECTION 4
OPERATION
MENU
Opens menu with available formats.
RETURN
Exits source window.
o Set Frequency, Shape, Level and Mode as
desired.
o If Audio/Data Filters are required for operation of Meters or Speaker, configure and
activate required filters.
T
e
n
High-Pass Filter/Low-Pass Filter combination and Bandpass Filter
never operate simultaneously on same Filter Line.
CONFIG
Accesses RF Generator Filters Menu when cursor is on
the Filter Line.
Select MOD METERS Bandpass Filter Field setting as follows:
OFF
Sets Filter to OFF.
C-MSG
Selects C-Message Weighted Filter.
Select MOD METERS High-Pass Filter Field setting as follows:
OFF
Sets Filter to OFF.
300Hz
Activates 300 Hz High-Pass Filter.
4kHz
Activates 4 kHz Low-Pass Filter.
EXEC
Executes all edits made to the screen.
Source: GEN1 State: ON
Format: TONE
Freq: 100.0 Hz
Shape: SINE
Level: 0.00 VP
.000 Vrms
Mode: CONT
DIO/DATA FIL
BAND
PASS
FILTER
OFF
EC" TO ACTIV
W.B.
OFF
OFF
OFF
LTERS SETUP
TIVATE SELEC
HIGH
PASS
FILTER
300Hz
OFF
OFF
OFF
